Our most narrow outdoor specification grade fixture great for edge and accent lighting in areas with limited space. The HB18 produces 400lm/ft. and is only 0.79” wide with single run lengths up to 277ft.”

Download

Data Sheets IES Catalog

HB1814

Wash, Cove and Accent

4w/ft. 400lm./ft.

Universal 120/277 vac

12", 24", 36", 48"

30°, 45°, 30°x60°

Static white

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB1828

Cove and Accent, Direct View

4w/ft. 180lm/ft.

Universal 120/277 vac

12", 24", 36", 48"

30°, 45°, 30°x60°

Static white

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB1856-RGBW

Cove and Accent, Direct View

4w/ft.

Universal 120/277 vac

12", 24", 36", 48"

120°

RGBW - 56 LED's/ft.

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Meet our most popular high-performance linear architectural outdoor lighting LED fixtures! The HB30 Series fixtures are compact at 1-1/4” wide designed to provide grazing, wall-washing with even illumination of up to 12ft for exterior applications.
Compatible Mounting Accessories optional and sold separately.

Download

Data Sheets IES Catalog

HB308

Graze, Wash, Cove and Accent

4.25 w/ft. 359 lm/ft.

120/277VAC

12", 24", 36", 48"

15°, 30°, 45°, 120°, 30°x60°

28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue

Non Dimming

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3014-ACD

Cove and Accent, Graze, Wash

4.5 w/ft. 7.5 w/ft. 458 lm/ft., 557 lm/ft.

120/277VAC

12", 24", 36", 48"

15°, 30°, 45°, 120°, 30°x60°

28k, 30k, 35k, 41k, 50k, 60k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES

HB3014-DC

Cove and Accent, Flood, Graze, Wash

6.5 w/ft. 480 lm/ft.

24VDC

12", 24", 36", 48"

15°, 30°, 45°, 120°, 30°x60°

28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3014R

Cove and Accent, Wash

4.5 w/ft. 7.5 w/ft. 365lm/ft., 458 lm/ft.

120/277VAC

12", 24", 36", 48"

120°

28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3015 RGB

Graze, Wash, Flood, Cove and Accent

5.6 w/ft.

120/277VAC

12", 24", 36", 48"

15°, 30°, 45°, 120°, 30°x60°

RGB (3 channel)

DMX - Addressable every 12”

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3016 RGBW

Wash, Cove and Accent, Flood, Graze

5.6 w/ft. 216lm/ft

120/277VAC

12", 24", 36", 48"

15°, 45°, 120°, 30°x60°

15°, 20°, 30°, 45°, 120°, 30°x60°

RGBW

DMX - Addressable every 12”

IP66 – Wet location

5-YEAR LIMITED WARRANTY

The HB30PD Series is a direct-view architectural linear designed for exterior edge or accent lighting. This fixture is made with a continuous 1-piece polycarbonate housing. The domed lens provides a vivid, even illumination without pixelation and is available in White, RGB & RGBW.

Download

Data Sheets IES Catalog

HB3024PD

Cove and Accent, Direct View

4.25 w/ft. 346lm/ft.

120/277VAC

12", 24", 36", 48"

120°

28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3018PD RGB

Cove and Accent, Direct View

120/277VAC

12", 24", 36", 48"

120°

18 LED’s/ft. RGB(3 channel), RGB

DMX - Addressable every 4”

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Instructions Catalog

HB3036PD RGBW

Direct View, Cove and Accent

239lm/ft.

120/277VAC

12", 24", 36", 48"

120°

18 RGB + 18 White

DMX - Addressable every 12”

IP66 – Wet location

5-YEAR LIMITED WARRANTY

The HB40HP series is a powerful architectural linear fixture ideal for applications up to 35ft. Select from multiple optics for grazing, wall-washing and general illumination.
Compatible Mounting Accessories optional and sold separately.

Download

Data Sheets IES Instructions Catalog

HB40HP

Cove and Accent, Graze, Wash, Flood

8.8 w/ft. 689 lm/ft.

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°

28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB40HP RGB

Cove and Accent, Graze, Flood, Wash

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 30°x60°

RGB (3 channel) – 12 LEDs/ft. (4R, 4G, 4B)

DMX - Addressable every 9"

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB40HP RGBW

Cove and Accent, Graze, Wash, Flood

13 w/ft. 641lm/ft.

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 30°x60°

RGBW - 16 LEDs/ft. (4R, 4G, 4B, 4W)

DMX - Addressable every 9"

IP66 – Wet location

5-YEAR LIMITED WARRANTY

The HB40SP illuminates up to 45ft. The LED board can be angled up to 20 degrees toward the surface you are illuminating. Extruded aluminum covers conceal the wiring for a clean, finished look. The anodized aluminum housing with tooled end caps ensures this fixture can withstand the harshest environments.
Compatible Mounting Accessories optional and sold separately.

Download

Data Sheets IES Catalog

HB40SP

Graze, Wash, Flood, Cove and Accent

8.8w/ft 649lm/ft; 12w/ft 853lm/ft

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°

28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB40SP RGB

Cove and Accent, Graze, Wash, Flood

13 w/ft.

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 30°x60°

RGB – 12 LEDs/ft

DMX - Addressable every 9"

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES Catalog

HB40SP RGBW

Cove and Accent, Graze, Wash, Flood

13 w/ft. 634lm/ft.

120/277VAC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 30°x60°

RGBW – 16 LEDs/ft

DMX - Addressable every 9"

IP66 – Wet location

5-YEAR LIMITED WARRANTY

View Cart

Details

Download

Data Sheets

HB40HP 24VDC

Graze, Wash, Flood, Cove and Accent

8.8 w/ft. 689 lm/ft.

24VDC

10", 19", 28", 37", 46"

15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°

28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue

0-10v Dimming

IP66 – Wet location

5-YEAR LIMITED WARRANTY

Download

Data Sheets

HB5224 RGB

Flood

12 w/ft.

100/277VAC

12", 24", 36", 48"

120°

RGB

DMX - Addressable every 12”

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES

HB5242

Flood

18w/ft 2070lm/ft

100/277VAC

12", 24", 36", 48"

120°

27k, 30k, 35k, 41k, 50k, 65k

0-10v Dimming

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

Download

Data Sheets IES

HB5228

Flood

11.25w/ft 1450lm/ft

100/277VAC

12", 24", 36", 48"

120°

27k, 30k, 35k, 41k, 50k, 65k

0-10v Dimming

IP66 – Wet location

90,000 hours

5-YEAR LIMITED WARRANTY

The HB50 Series are powerful exterior linear fixtures capable of illuminating over 8 stories! Luminaires can be specified with various optics for grazing and wall washing and are available in static colors, RGB or RGBW.
Compatible Mounting Accessories optional and sold separately.
