• HB40HP is an architectural fixture ideal for powerful illumination between 15-35ft. Choose from optics for grazing, wall-washing and general illumination.
    Compatible Mounting Accessories optional and sold separately.

    HB40HP

    , , ,
    8.8 w/ft. 689 lm/ft.
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB40HP RGB

    , , ,
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB (3 channel) – 12 LEDs/ft. (4R, 4G, 4B)
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB40HP RGBW

    , , ,
    13 w/ft.
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW - 16 LEDs/ft. (4R, 4G, 4B, 4W)
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • The HB40SP illuminates up to 45ft depending on optics. This series allows for additional fine-tuning of the beam with the adjustable optical board (+/-20°). The anodized aluminum housing with tolled end caps ensures this fixture can withstand the harshest environments.
    Compatible Mounting Accessories optional and sold separately.

    HB40SP

    , , ,
    8.8w/ft 649lm/ft; 12w/ft 853lm/ft
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB40SP RGB

    , , ,
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB – 12 LEDs/ft
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets Catalog

    HB40SP RGBW

    , , ,
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW – 16 LEDs/ft
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB40HP 24VDC

    , , ,
    8.8 w/ft. 689 lm/ft.
    24VDC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
