• Meet our most popular high-performance linear architectural outdoor lighting LED fixtures! The HB30 Series fixtures are compact at 1-1/4” wide designed to provide grazing, wall-washing and general illumination of up to 12ft for exterior applications.
    Compatible Mounting Accessories optional and sold separately.

    Download
    Data Sheets Catalog

    HB308

    , ,
    4.25 w/ft. 359 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    Non Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3014-ACD

    , ,
    4.5 w/ft. 458 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 60k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES

    HB3014-DC

    , , ,
    6.5 w/ft. 480 lm/ft.
    24VDC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • The HB30i Series is a high-quality spec-grade indoor architectural lighting fixture offering high-performance in a small, low-profile package – max 1.76"h x 1.26"w.. Architects and lighting designers love this Series for its versatility! This technological innovation offers graze and wash options for direct or indirect illumination. Fixtures are available in a variety of static colors as well as RGB and RGBW. You can also choose between flat and dome lenses with clear and opaque options.

    HB308i

    , ,
    4.4 w/ft. 359 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    Non Dimming
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3014i

    , ,
    4.4 w/ft. 458 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3014R

    ,
    4.5 w/ft. 365lm/ft.
    120/277VAC
    12", 24", 36", 48"
    120°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3015 RGB

    , , ,
    5.6 w/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    RGB (3 channel)
    DMX - Addressable every 12”
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3016 RGBW

    , , ,
    5.6 w/ft. 360 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 45°, 120°, 30°x60°
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW
    DMX - Addressable every 12”
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • The HB30PD is a direct-view architectural linear perfect for exterior edge or accent lighting. The domed lens provides a continuous glow without pixelation and is available in RGB or RGBW.

    HB3024PD

    ,
    4.25 w/ft. 328 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    120°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3018PD RGB

    ,
    120/277VAC
    12", 24", 36", 48"
    120°
    18 LED’s/ft. RGB(3 channel), RGB
    DMX - Addressable every 4”
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3036PD RGBW

    ,
    120/277VAC
    12", 24", 36", 48"
    120°
    18 RGB + 18 White
    DMX - Addressable every 12”
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • HB3014ir

    4.4 w/ft. 356 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    120°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3024if

    , ,
    4.4 w/ft. 458 lm/ft.
    120/277VAC
    12", 24", 36", 48"
    120°
    28k, 30k, 35k, 41k, 50k, 65k
    0-10v Dimming
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3015i RGB

    , , ,
    6 w/ft.
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    RGB (3 channel)
    DMX - Addressable every 12”
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3016i RGBW

    , , ,
    120/277VAC
    12", 24", 36", 48"
    15°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k
    DMX - Addressable every 12”
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • HB3018ir RGB

    ,
    120/277VAC
    12", 24", 36", 48"
    120°
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB (3 channel)
    DMX - Addressable every 6"
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
  • The HB50 Series feature exterior high-powered LED linear fixtures for building and façade capable of illuminating over 8 stories! Luminaires can be specified with various optics and are available in static colors, RGB or RGBW.
    Compatible Mounting Accessories optional and sold separately.

    HB50B

    , , ,
    12 w/ft. 16 w/ft. 20 w/ft. 1040 lm/ft., 1400 lm/ft., 780 lm/ft.
    100/277VAC
    12", 24", 36", 48"
    8°, 15°, 20°, 30°, 45°, 120°, 8°x40°, 13°x17°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    50,000 min lifetime rated
    5-YEAR LIMITED WARRANTY
  • HB3036ir RGBW

    ,
    5.6 w/ft.
    120/277VAC
    12", 24", 36", 48"
    120°
    RGBW
    DMX - Addressable every 12”
    IP40 rated - Dry location
    5-YEAR LIMITED WARRANTY
