20°

  • The HB40HP series is a powerful architectural linear fixture ideal for applications up to 35ft. Select from multiple optics for grazing, wall-washing and general illumination.
    Compatible Mounting Accessories optional and sold separately.

    Download
    Data Sheets IES Instructions Catalog

    HB40HP

    , , ,
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB40HP RGB

    , , ,
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB (3 channel) – 12 LEDs/ft. (4R, 4G, 4B)
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB40HP RGBW

    , , ,
    13 w/ft. 641lm/ft.
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW - 16 LEDs/ft. (4R, 4G, 4B, 4W)
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY

  • The HB40SP illuminates up to 45ft. The LED board can be angled up to 20 degrees toward the surface you are illuminating. Extruded aluminum covers conceal the wiring for a clean, finished look. The anodized aluminum housing with tooled end caps ensures this fixture can withstand the harshest environments.
    Compatible Mounting Accessories optional and sold separately.

    Download
    Data Sheets IES Catalog

    HB40SP

    , , ,
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB40SP RGB

    , , ,
    13 w/ft.
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB – 12 LEDs/ft
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB40SP RGBW

    , , ,
    13 w/ft. 634lm/ft.
    120/277VAC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW – 16 LEDs/ft
    DMX - Addressable every 9"
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY
  • View Cart
    Details
    Download
    Data Sheets

    HB40HP 24VDC

    , , ,
    8.8 w/ft. 689 lm/ft.
    24VDC
    10", 19", 28", 37", 46"
    15°, 20°, 30°, 45°, 120°, 13°x17°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    5-YEAR LIMITED WARRANTY

  • The HB50 Series are powerful exterior linear fixtures capable of illuminating over 8 stories! Luminaires can be specified with various optics for grazing and wall washing and are available in static colors, RGB or RGBW.
    Compatible Mounting Accessories optional and sold separately.

    Download
    Data Sheets IES Catalog

    HB50B

    , , ,
    12 w/ft. 16 w/ft. 20 w/ft. 1040 lm/ft., 1400 lm/ft., 780 lm/ft.
    100/277VAC
    12", 24", 36", 48"
    10°x60°, 15°x35°, 8°, 15°, 20°, 30°, 45°, 120°, 8°x40°, 13°x17°, 30°x60°
    28k, 30k, 35k, 41k, 50k, 65k, Red, Green, Blue
    0-10v Dimming
    IP66 – Wet location
    90,000 hours
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB50A RGB

    , , ,
    Universal 120/277 vac
    12", 24", 36", 48"
    10°x60°, 15°x35°, 15°, 20°, 30°, 45°, 120°, 30°x60°
    RGB – 18LEDs/ft
    DMX - Addressable every 12”
    IP66 – Wet location
    90,000 hours
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Catalog

    HB50C RGBW

    , , ,
    943lm/ft.
    Universal 120/277 vac
    12", 24", 36", 48"
    10°x60°, 15°x35°, 15°, 20°, 30°, 45°, 120°, 30°x60°
    RGBW / RGBA
    DMX - Addressable every 12”
    IP66 – Wet location
    90,000 hours
    5-YEAR LIMITED WARRANTY

  • Architectural linear system for indoor, indirect lighting applications for grazing or wall washing of walls, windows, narrow coves, and niches. Low-profile for applications such as retail, hotel, restaurant, museums and residential homes.

    Download
    Data Sheets IES Instructions Catalog

    SB8

    , , ,
    4.35 w/ft. 380 lm/ft.
    24VDC
    12", 24", 36", 48", 60", 66"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k
    0-10v Dimming
    IP44 Damp Location
    5-YEAR LIMITED WARRANTY
    Download
    Data Sheets IES Instructions Catalog

    SB12

    , , ,
    7 w/ft. 620 lm/ft.
    24VDC
    12", 24", 36", 48", 60", 66"
    15°, 20°, 30°, 45°, 120°, 30°x60°
    28k, 30k, 35k, 40k, 50k, 65k
    0-10v Dimming
    IP44 Damp Location
    5-YEAR LIMITED WARRANTY
